Cisco 3200 Series Hardware Reference

6-15
Cisco 3200 Series Router Hardware Reference
OL-5816-10
Chapter 6 Wireless Mobile Interface Cards
Modulation
Table 6-11 lists the supported 5.0-GHz (802.11h) modulations and data rates.
Receive Sensitivity
Table 6-12 shows the receive sensitivity for 5.0-GHz (802.11h) radios.
Transmit Sensitivity
Table 6-13 shows the transmit sensitivity for 5.0-GHz (802.11h) radios.
Ta b l e 6-11 5.0-GHz (802.11h) Modulations and Data Rates
Modulation 20 Mbps
BPSK
6 Mbps and 9 Mbps
QPSK
12 Mbps and 18 Mbps
16 QAM
24 Mbps and 27 Mbps
64 QAM
48 Mbps and 54 Mbps
Ta b l e 6-12 Receive Sensitivity for 5.0-GHz (802.11h) Radios
Data Rates 5.25 GHz to 5.35 GHz 5.47 GHz to 5.725 GHz 5.725 GHz to 5.825 GHz
1
1. The 5.725-GHz to 5.825-GHz range is not supported on European models.
6 Mbps -85 dBm -85 dBm -85 dBm
9 Mbps -85 dBm -85 dBm -85 dBm
12 Mbps -85 dBm -85 dBm -85 dBm
18 Mbps -82 dBm -82 dBm -82 dBm
24 Mbps -79 dBm -79 dBm -79 dBm
36 Mbps -76 dBm -76 dBm -76 dBm
48 Mbps -71 dBm -71 dBm -71 dBm
54 Mbps -69 dBm -69 dBm -69 dBm
Ta b l e 6-13 Transmit Sensitivity for the C3205 WMIC
Data Rates 5.25 GHz to 5.35 GHz 5.47 GHz to 5.725 GHz 5.725 GHz to 5.825 GHz
1
6 Mbps 16 dBm 16 dBm 16 dBm
9 Mbps 16 dBm 16 dBm 16 dBm
12 Mbps 16 dBm 16 dBm 16 dBm
18 Mbps 16 dBm 16 dBm 16 dBm
24 Mbps 16 dBm 16 dBm 16 dBm
36 Mbps 16 dBm 16 dBm 16 dBm
48 Mbps 14 dBm 14 dBm 14 dBm
54 Mbps 13 dBm 13 dBm 13 dBm
