Cisco Catalyst 3560-CX User Manual

DescriptionSoftware
Switch Model
12 10/100/1000 Ethernet ports; 2 Gigabit Ethernet and 2 SFP module
uplink slots.
IP BaseWS-3560CX-12TC-S
12 10/100/1000 PoE+ ports (PoE budget of 240 W); 2 Gigabit Ethernet
and 2 SFP+
2
module uplink slots.
IP BaseWS-3560CX-12PD-S
8 10/100/1000 PoE+ ports (PoE budget of 146W); 2 Gigabit Ethernet
uplink ports.
IP BaseWS-3560CX-8PT-S
2 Multigigabit
3
100/1000/2500/5000/10000 PoE+ ports; 6 10/100/1000
PoE+ ports (PoE budget of 240 W); 2 SFP+ module uplink slots.
IP BaseWS-3560CX-8XPD-S
8 Gigabit Ethernet PoE+ ports; and 2 SFP module uplink slots.IP BaseWS-C3560CPX-8PT-S
6 Gigabit Ethernet ports; 2 multi-Gigabit Ethernet PoE+ ports; and 2
SFP+ uplink slots.
IP BaseWS-C3560CX-8PD-S
8 10/100/1000 PoE+ ports (PoE budget of 124 W); 2 Gigabit Ethernet
and 2 SFP module uplink slots.
LAN BaseWS-2960CX-8PC-L
8 10/100/1000 Ethernet ports; 2 Gigabit Ethernet and 2 SFP module
uplink slots.
LAN BaseWS-2960CX-8TC-L
1
SFP = Gigabit uplink.
2
SFP+ = 10-Gigabit uplink.
3
Multigigabit ports support speeds of 100 Mbps, 1 Gbps, 2.5 Gbps, and 5 Gbps on Category 5e cable and up to 10 Gbps over Category 6a cabling
IP Base switches can be upgraded to IP Services with the RTU (right to use) software license.Note
Front Panel
•
8 or 12 downlink Ethernet ports of one of these types:
◦
10/100/1000
◦
10/100/1000 PoE+
The Catalyst 3560CX-8XPD-S has 6 PoE+ ports and 2 Multigigabit PoE+ ports.Note
•
Two 10/100/1000 uplink ports and two SFP or SFP+ module ports depending on the switch model.
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
2
Product Overview
Front Panel
