If the FAN LED is still red, the system detects an individual fan failure. Contact a customer service
representative for instructions.
Status LED Indicators
ActionComponentAlarm TypeStatus LED
Indication
Syslog message and SNMP trap
generated.
If redundancy is configured, the
system switches to the redundant
supervisor engine and the active
supervisor engine shuts down.
If there is no redundancy and the
overtemperature condition is not
corrected, the system shuts down
after 5 minutes.
Chassis temperature sensor
exceeds major threshold.
MajorRed
Syslog message and SNMP trap
generated.
Monitor the condition.
Chassis temperature sensor
exceeds minor threshold.
MinorOrange
Syslog message and SNMP trap
generated.
If major alarm and the
overtemperature condition is not
corrected, the system shuts down
after 5 minutes.
If minor alarm, monitor the
condition.
Redundant supervisor
engine temperature sensor
exceeds major or minor
threshold.
Major
Minor
Red
Orange
Contacting Cisco Customer Service
If you are unable to solve a startup problem after using the troubleshooting suggestions in this chapter, contact
a Cisco customer service representative for assistance and additional instructions. Before you call, have the
following information ready to help your service provider assist you as quickly as possible:
•
Date on which you received the switch
•
Chassis serial number
•
Type of software and release number
Catalyst 6880-X Switch Hardware Installation Guide
106 OL-30827-02
Troubleshooting
Status LED Indicators
