DC-Input Power Supply LEDs
The 3000 W DC-input power supply includes LEDs on the front of the module. The different states of the
LEDs are described in the following table.
Figure 8: DC-Input Power Supply LED Locations
On/Off switch2Location of LEDs on DC-input power supply1
Table 10: DC-Input Power Supply LED Indicators
DescriptionColor/StateLED
Primary DC input current is at acceptable
level.
Solid greenIN1
Primary DC input current is outside valid
range.
Blinking greenIN1
Secondary DC input current is at acceptable
level.
Solid greenIN2
Secondary DC input current is outside valid
range.
Blinking greenIN2
Output DC current is at acceptable level.Solid greenOUT
Output DC current is outside valid range.Blinking greenOUT
Power supply unit is functioning normally.OffFAULT
The unit has failed self-diagnostic test or is
not operational.
Blinking redFAULT
