Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 1 Overview of the Content Delivery Engines
Hardware Features
CDE420 4G-C
Figure 1-37 is a front view of the CDE420 (all models) showing the location of the storage drives.
Table 1-44 lists the CDE420 4G-C PCI expansion cards and their corresponding PCI slot numbers (see
Figure 1-12 to see the location of the PCI expansion slots).
CDE420 4G-F
Figure 1-37 is a front view of the CDE420 (all models) showing the location of the storage drives.
Table 1-45 lists the CDE420 4G-F PCI expansion cards and their corresponding PCI slot numbers (see
Figure 1-12 to see the location of the PCI expansion slots).
Table 1-44 CDE420 4G-C PCI Expansion Cards
PCI Expansion
Slot Number
Expansion Card Interface Name
(top to bottom)
1— —
2 NIC—quad copper eth6 eth7 eth8 eth9
3 NIC—quad copper eth2 eth3 eth4 eth5
4— —
5 NIC—quad copper eth10 eth11 eth12 eth13
6— —
7— —
Table 1-45 CDE420 4G-F PCI Expansion Cards
PCI Expansion
Slot Number
Expansion Card Interface Name
(top to bottom)
1— —
2 NIC—dual fiber eth6 eth7
3 NIC—dual fiber eth2 eth3
4— —
5 NIC—dual fiber eth10 eth11
6— —
7— —
