PurposeCommand or Action
◦
Entering cancel leaves the router in the current configuration
session without exiting or committing the configuration
changes.
•
Use the commit command to save the configuration changes to
the running configuration file and remain within the configuration
session.
Configuring the RTSP ALG for NAT44 Instance
Perform this task to configure the ALG for the rtsp for the specified NAT44 instance. RTSP packets are
usually destined to port 554. But this is not always true because RTSP port value is configurable.
SUMMARY STEPS
1.
configure
2.
service cgn instance-name
3.
service-type nat44 nat1
4.
alg rtsp [server-port] value
5.
end or commit
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Configures the instance named cgn1 for the CGN application and enters
CGN configuration mode.
service cgn instance-name
Example:
RP/0/RP0/CPU0:router(config)# service
cgn cgn1
RP/0/RP0/CPU0:router(config-cgn)#
Step 2
Configures the service type keyword definition for NAT44application.service-type nat44 nat1
Example:
RP/0/RP0/CPU0:router(config-cgn)#
service-type nat44 nat1
Step 3
Cisco IOS XR Carrier Grade NAT Configuration Guide for the Cisco CRS Router, Release 5.2.x
38 OL-32659-01
Implementing Carrier Grade NAT on Cisco IOS XR Software
Configuring the Policy Functions for the Carrier Grade NAT
