PurposeCommand or Action
Configures the instance named cgn1 for the CGN application and enters
CGN configuration mode.
service cgn instance-name
Example:
RP/0/RP0/CPU0:router(config)# service
cgn cgn1
RP/0/RP0/CPU0:router(config-cgn)#
Step 2
Configures the active and standby locations for the CGN application.
service-location preferred-active node-id
[preferred-standby node-id]
Step 3
Example:
RP/0/RP0/CPU0:router(config-cgn)#
service-location preferred-active
0/1/CPU0 preferred-standby 0/4/CPU0
Saves configuration changes.end or commit
Example:
RP/0/RP0/CPU0:router(config-cgn)# end
or
RP/0/RP0/CPU0:router(config-cgn)# commit
Step 4
•
When you issue the end command, the system prompts you to
commit changes:
Uncommitted changes found, commit them before exiting
(yes/no/cancel)?
[cancel]:
◦
Entering yes saves configuration changes to the running
configuration file, exits the configuration session, and returns
the router to EXEC mode.
◦
Entering no exits the configuration session and returns the
router to EXEC mode without committing the configuration
changes.
◦
Entering cancel leaves the router in the current configuration
session without exiting or committing the configuration
changes.
•
Use the commit command to save the configuration changes to
the running configuration file and remain within the configuration
session.
Configuring Multiple Public Address Pools
Perform the following steps to configure multiple public address pools for an inside VRF.
Cisco IOS XR Carrier Grade NAT Configuration Guide for the Cisco CRS Router, Release 5.2.x
48 OL-32659-01
Implementing Carrier Grade NAT on Cisco IOS XR Software
Configuring the Policy Functions for the Carrier Grade NAT
