Maximum Power Available for 3-kW AC Power Supplies
The maximum power available for operations depends on the input power from your power source, the number
and output capabilities of your power supplies, and the power redundancy mode that you use. The following
table lists the amount of power available for 3-kW power supplies depending on power inputs, numbers of
power supplies, and the mode used.
Full Redundancy
Mode
Input Source
Redundancy
Mode
Power Supply
Redundancy
Mode
Combined ModePower SuppliesPower Inputs
———3000 W11 input (220 V)
3000 W3000 W3000 W6000 W2
3000 W3000 W6000 W9000 W3
6000 W6000 W9000 W12000 W4
6000 W6000 W12000 W15000 W5
9000 W9000 W15000 W18000 W6
9000 W9000 W18000 W21000 W7
12000 W12000 W21000 W24000 W8
—
——1450 W11 input (110 V)
1450 W1450 W1450 W2900 W2
1450 W1450 W2900 W4350 W3
2900 W2900 W4350 W5800 W4
2900 W2900 W5800 W7250 W5
4350 W4350 W7250 W8700 W6
4350 W4350 W8700 W10150 W7
5800 W5800 W10150 W11600 W8
Maximum Power Available for 3-kW DC Power Supplies
The maximum power available for operations depends on the input power from your power source, the number
and output capabilities of your power supplies, and the power redundancy mode that you use. The following
table lists the amount of power available for 3-kW DC power supplies depending on power inputs, numbers
of power supplies, and the mode used.
Cisco Nexus 7710 Switch Site Preparation and Hardware Installation Guide
OL-30452-01.78
Managing the Switch
Maximum Power Available for 3-kW AC Power Supplies
