3-17
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-11
Chapter 3 Installing and Configuring Route Switch Processors and Supervisor Engines
Configuring a Supervisor Engine or Route Switch Processor
Note If you are upgrading the RP, then slot 1 and slot 2 DIMMs should be of same vendor. If there is only one
DIMM for RP, then install it in slot 1.
To upgrade SP DIMM to 2 GB, follow these steps:
Step 1 Remove the DIMM from slot 3.
Step 2 Install the new DIMM of 2 GB memory size in slot 3.
To upgrade RP DIMM to 2 GB, follow these steps:
Step 1 Remove the I GB DIMM from slot 1.
Step 2 Install the new 1 GB DIMM in slot 1.
Step 3 Install the new 1 GB DIMM in slot 2.
To upgrade RP DIMM to 4 GB, follow these steps:
Step 1 Remove the 1 GB DIMM from slot 1.
Step 2 Install the new 2 GB DIMM in slot 1.
Step 3 Remove the 1 GB DIMM from slot 2 (if present).
Step 4 Install another 2 GB DIMM in slot 2.
Configuring a Supervisor Engine or Route Switch Processor
See the Cisco 7600 Series Router Cisco IOS Software Configuration Guide for information about how
to configure the supervisor engine or route switch processor for operation.
