Cisco WS-SUP720-3B - Supervisor Engine 720 User Manual

B-20
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-11
Appendix B Cable and Connector Specifications
LX/LH GBIC and MMF Cable Considerations
Figure B-8 Patch Cord Configuration
Patch Cord Installation
Warning Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into
beams or view directly with optical instruments. Statement 1051
Plug the end of the patch cord labeled “To Equipment” into the GBIC (see Figure B-9). Plug the end
labeled “To Cable Plant” into the patch panel. The patch cord is 9.84 feet (3 meters) long and has duplex
SC male connectors at each end.
Figure B-9 Patch Cord Installation
1000BASE-LX/LH
port
Patch
panel
Link span greater than 984 ft
(300 m)
1000BASE-LX/LH
port
Rx
Tx
Patch
panel
Patch
cord
Building
cable plant
Tx
Rx
Patch
cord
13088
To equipment To cable plant
13089
