Appendix B Cable and Connector Specifications
Uplink Port Transceiver Modules
Table B-7 lists the cabling specifications for 10GE uplink ports, which are located on X2 or XENPAK
transceiver modules that plug into the RSP720-10GE and WS-SUP32-10GE-3B front panel.
Note The 10GE uplink ports on the RSP720-10GE support X2 transceiver modules only.
GBIC Module Cabling Specifications
Table B-8 provides cabling specifications for the 1000BASE-X interfaces on the Gigabit Interface
Converter (GBIC) modules installed in the Supervisor Engine 2. All GBIC interfaces have SC
connectors, and the minimum cable distance for all GBICs listed (MMF and SMF) is 6.5 feet (2 meters).
Table B-7 10GE Cabling Specifications
X2 Device
(Product ID)
Wavelength
(nm)
Fiber Type
(MHz km)
Core Size
(micron)
Modal Bandwidth
(MHz km) Cable Distance
1
1. Minimum cabling distance for -LR, -SR, -LX4, and -ER modules is 2 m, according to the IEEE 802.3ae standard.
X2-10GB-SR
XENPAK-10GB-SR
850 MMF 62.5
62.5
50
50
50
160
200
400
500
2000
85.3 ft (26 m)
108.3 ft (33 m)
216.5 ft (66 m)
269.0 ft (82 m)
984.3 ft (300 m)
X2-10GB-LR
XENPAK-10GB-LR
1310 SMF ITU-T
G.652
— 6.2 mi (10 km)
X2-10GB-ER
2
XENPAK-10GB-ER
2. Requires 5 dB 1550 nm fixed loss attenuator for < 20 km. Attenuator is available as a spare. The part number is WS-X6K-5DB-ATT=.
1550 SMF ITU-T
G.652
— 24.9 mi (40 km)
3
3. Links longer than 30 km are considered engineered links.
X2-10GB-LX4
XENPAK-10GB-LX4
1310 MMF 62.5
50
50
500
400
500
984.3 ft (300 m)
787.4 ft (240 m)
984.3 ft (300 m)
X2-10GB-CX4
XENPAK-10GB-CX4
— CX4 (copper) — — 49.2 ft (15 m)
X2-10GB-LRM 1310 MMF 62.5
50.0
50.0
500
400
500
220 m (722 feet)
100 m (328 feet)
220 m (722 feet)
X2-10GB-ZR 1550 SMF G.652 fiber — 80 km (49.72 miles)
4
4. When shorter distances of SMF are used, an inline optical attenuator (10 dB) must be used to avoid overloading and damaging the receiver.
