Clarion CZ302E User Manual

English
13
CZ302E
MIC
7) Wiring and Connections
Refer to next page.
A
B
2
4
6
8
1
3
5
7
1
3
5
7
2
4
6
8
Rear Right / SUB OUT 2
Rear Left / SUB OUT 1
SWC
Refer to next page
Rear audio output (Left)/
White
Red
4 Channel Amplier
Antenna
Black
Black
Black
Black
Black
Black
(Black)
Rear audio output (Right)/
Steering wheel
control terminal
External
microphone
Subwoofer output 1
Subwoofer output 2
(RCB-199:Sold by separately)
C
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
right part.
2. Push the trim ring to left and pull out the
left part.
Disassemble the unit
1. Switch off the power.
2. Remove the panel.
3. Remove the trim ring.
4. Insert the removal keys straight back until
they lock, then pull the unit out.
5. Disconnect all the wires.
Method B
6) Removing the Source Unit
Mounting Frame
Dashboard
M5x6
1. Insert this unit directly to the opening of
the dashboard.
2. Place M5×6 cylindrical screw through the
holes of the mounting frame located inside
the opening to holes of the unit and fasten
the screws to left & right.
Trim Ring Installation
Attach the trim ring around the front panel.
Disassemble trim ring
1. Push the trim ring to right and pull out the
Top
Bottom
White
Gray
Red
Left
Right
Front audio
output terminal

Clarion CZ302E Specifications

General

MP3 playback	Yes
Audio formats supported	MP3, WMA
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HFP, HSP, PBAP
Line outputs (RCA)	4
USB ports quantity	1
DIN size	-
Output power	80 W
Product color	Black
Volume control	Rotary
Frequency range	20 - 20000 Hz
Disc types supported	CD
Audio output channels	4.0 channels
Maximum power per channel	20 W
Signal-to-Noise Ratio (SNR)	94 dB
FM band range	87.5 - 108 MHz
Supported radio bands	FM, LW, MW
Display type	LCD

Weight and Dimensions

Weight	1350 g
Dimensions (WxDxH)	188 x 190 x 58 mm
