Specifications
D - 2 Specifications
D
Display
13.3” / 33.78cm QHD+ (3200 * 1800),
FHD (1920 * 1080), HD+ (1600 * 900),
16:9, 2.85mm Thick Backlit Panel
Memory
Dual Channel DDR4
Two
260 Pin SO-DIMM Sockets
Supporting DDR4 2400 MHz Memory
Modules (real operational frequency
depends on the FSB of the processor)
Memory Expandable up to 32GB
Compatible with 4GB, 8GB or 16GB
Modules
Storage
One Changeable 2.5" / 7.0 mm (h) HDD/
SSD with SATA (Serial) Interface
One M.2 SSD 2280, SATA/PCIe Gen 3x4
Interface
(
Factory Option)
Audio
High Definition Audio Interface
Built-In Microphone
2 * Built-In Speakers
Built-In Array Microphone (
Factory Option
)
Pointing Device & Keyboard
Built-in TouchPad with Microsoft PTP
Multi-Gesture and Scrolling Functionality
A4 Size Isolated Keyboard with Numeric
Keypad
OR
A4 Size Isolated White Illuminated
Keyboard with Numeric Keypad (Factory
Option)
Interface
Two USB 3.0
(USB 3.1 Gen 1)
Ports
(Type-A)
One
USB 3.0 (USB 3.1 Gen 1) Port (Type-C)
OR
One Thunderbolt™ 3 Port
(
Factory
Option
)
===============================
*Note: The maximum amount of current supplied
by USB Type-C ports is 500 mA for USB2.0/900
mA for USB 3.1
===============================
One Mini DisplayPort 1.2
One HDMI-Out (High-Definition
Multimedia Interface) Port (with HDCP)
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-In Jack
Card Reader
Embedded Multi-In-1 Card Reader
- MMC/ RS MMC
- SD/ Mini SD / SDHC/ SDXC
Note: Some cards require PC adapters
that are usually supplied with the cards.
Slot
Three M.2 Card Slots:
Slot 1
for M.2 2230 WLAN Combo Module
with PCIe & USB Interfaces (A Key)
Slot 2
for SSD M.2 2280 Card with SATA
/ PCIe Gen 3*4 Interface
(M Key
)
Slot 3:
for
M.2 3042 LTE/HSPA+
3G OR
4G Module
with USB Interface
(
Factory
Option
) - (B Key)
Communication
Built-In 10/100/1000Mb Base-TX
Ethernet LAN
To Next Page
