Figure 1 - 9
Bottom View
1. RJ-45 LAN Jack
2. Vent/Fan Intake/
Outlet
3. Speakers
Bottom Cover
Appearance
Note that some design
styles will have a bottom
cover that differs in ap-
pearance slightly form
that pictured here.
Overheating
To prevent your comput-
er from overheating
make sure nothing blocks
the Vent/Fan Intake while
the computer is in use.
Bottom Cover Removal Warning
Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may
violate the terms of your warranty.
If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, please
contact your distributor/supplier for further information.
2
2
1
33
