Page 10
HEAT PUMP
SET HEAT PUMP OPERATION
Information displayed:
• supply water temperature
• return water temperature
• % capacity of the compressor
• operation status (heating/cooling/off)
• components found in the system (radiators, fan coils and
radiant panels) and relative status (enabled / excluded).
2 - Automatic operation:
The heat pump is used to produce both air-conditioning system
water and domestic hot water.
3 - For domestic hot water only:
The heat pump is used only to produce domestic hot water.
4 - Deactivate the heat pump:
The heat pump is switched off
5 - Distribution:
Displays the components in the system and the water temperature.
The operation of single components of the system can be enabled or
excluded:
select 6, 7 or 8 to Exclude / Enable
Example
6 - Radiators:
Excluded
7 - Radiant panels:
Enabled
8 - Terminals:
Enabled
2
3
4
5
6
1
select 1
select 5
7 8
To Next Page
