Page 41
SYSTEM ACCESSORIES
AL12X
230/1/50 feeder - 12Vdc for Modbus
thermostats;
4 DIN modules
CIECX
Uncased pre-installation box for
ELFOControl
2
216x168x73 LxHxP
CBSX
Shielded cable for RS485 bus;
Installation
Domestic hot water
KGPRX
Mixing unit control module;
210x155x80 LxHxP
BMZRX
Radiant area module with RS485
communication port + TTL/485 converter
for Modbus thermostats;
9 DIN modules + 2 DIN modules of the
TTL/485 converter
CMRSX
Single area module with RS485
communication port;
6 DIN modules + 2 DIN modules of the
TTL/485 converter
Radiant panels - Ambient terminals
Termostats
+
-
GND
LN
AP2
AP1
MIOX
Input/output module with RS485
communication port;
6 DIN modules
Components of the system
From ElfoControl
2
it is possible to set:
• Temperatures and time bands of domestic hot water
production;
• HP priority for comfort or domestic hot water;
• Antilegionella cycle scheduling.
Elfocontrol
2
222x43x168 LxHxP
230/1/50 feeder - 12Vdc
4 DIN modules
Ethernet/485 converter
3 DIN modules
Elfocontrol
2
CACSX
Domestic hot water control kit;
290x410x140 LxHxP
ACS300X
300 litres DWH tank;
600x1615 ØxH
ACS500X
500 litres DWH tank;
750x1690 ØxH
ACS3SX
300 litres DHW tank with solar coil;
600x1615 ØxH
ACS5SX
500 litres DHW tank with solar coil;
750x1690 ØxH
CMACSX
Domestic hot water module;
300x220x120 LxHxP
HID-T2X
HID-T2
local electronic room control
device (temperature only);
127x86x27 LxHxP
HID-T3X
HID-T3 local electronic room control
device (temperature + humidity);
127x86x27 LxHxP
HID-TI2X
HID-Ti2 local electronic room control
device (uncased, temperature only);
In built-in 503 box
HID-TI4NX (black) - HID-TI4BX (white)
HID-T14 Modbus electronic room control
device (uncased)
In built-in 503 box
Compatible with plates type:
AVE system 44
HID-URNX (black) - HID-URBX (white)
HID-UR Modbus relative humidity sensor
(uncased)
In built-in 503 box (by only)
In built-in 504 box ( with HID-TI4)
To Next Page
