Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
28
StartButnEcho
StopButnEcho
FltButnEcho
HrnButnEcho
GCBButnEcho
These outputs are active for 1s if the corresponding button is pressed or binary input gets active or
corresponding remote command is issued (from PC software, SMS, ...).
CtrlHeartBeat
The output signalizes watchdog reset. In a healthy state it flashes at 500ms : 500ms rate. It stops flashing
when the unit reset occurs and the new controller start-up fails.
Logical 0
Constant value that can be configured to any output.
Logical 1
Constant value that can be configured to any output.
Binary outputs – Fixed protection outputs
Horn
The output closes if any alarm comes up. It opens if FAULT RESET or HORN RESET is pressed or if
Engine protect: Horn timeout has elapsed. The output closes again if a new fault comes up.
Alarm
The output closes if any alarm comes up. It opens if FAULT RESET is pressed. The output closes again if a
new fault comes up.
Common Wrn
The output closes if any “Warning”-type alarm appears. The output opens, if no “Warning”-type alarm is
active and FAULT RESET has been pressed.
Common Sd
The output closes if any “Shutdown”-type alarm appears. The output opens, if no “Shutdown”-type alarm is
active and FAULT RESET has been pressed.
Common Stp
The output closes if any “Slow stop”-type alarm appears. The output opens, if no “Slow stop”-type alarm is
active and FAULT RESET has been pressed.
Common Fls
The output closes if any “Fail sensor”-type alarm appears. The output opens, if no “Fail sensor”-type alarm is
active and FAULT RESET has been pressed.
Common OfL
The output closes if any “Off load”-type alarm appears. The output opens, if no “Off load”-type alarm is
active. No FAULT RESET needed.
