Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
34
Setpoints
Password protection
Any setpoint can be password protected - 7 levels of password is available. The password is a four-digit
number. Only setpoints associated with the entered password level can be modified.
Even though one level may have been set from the front panel, the affected setpoints are not
accessible from InteliMonitor (direct or Modem) until this level is set in IMON.
Setpoints opened from front panel are automatically closed 15 minutes after the last key has been
pressed or when wrong value of password is set.
Any password can be changed once that level password or higher has been entered. The controller
programming (configuration) requires the highest - password 7 level.
ProcessControl
#SysBaseLoad [ kW ]
From this value, the requested gen-set load is calculated, according to the number of gen-sets running. The
complete system produces the power equal to this value. Active only when SysLdCtrl PtM = BASELOAD.
Step: 1 kW
Range: 0 – 65000 kW
Hint:
If you set this setpoint to a higher value than the system is available to produce, the total produced power is
limited with the sum of Nomin power setpoints of all gen-sets in the system.
LocalBaseload [ kW ] (FV)
If the value is OFF, the gen-set takes part in the #SysBaseload production or in Load Sharing. If it is set to a
certain value, the gen-set produces this power regardless of the other gen-sets. It is taken out from the PMS
in this case.
Step: 1 kW
Range: OFF, 1 - Nomin power
Force value: Yes
Hint:
If the gen-sets operate in island parallel mode, the requested LocalBaseload value can be reduced if the
actual load is lower than this value. The gen-sets in the group will try to match their LocalBaseloads based
on their addresses, so the first limited would be the one with the highest CAN address.
#SysPwrFactor [ ]
Requested gen-set power factor when #SysPFCtrl PtM = BASEPF. Values 0,60 – 0,99 correspond to lagging
(inductive, L) PF, 1,01 – 1,20 correspond to leading (capacitive, C) PF.
Step: 0,01
Range: 0,60 - 1,20
#SysLdCtrl PtM [ BASE LOAD / LDSHARING ]
BASE LOAD The gen-set is a part of the System delivered power control (#SysBaseLoad) and
produces a certain part of it, according to the actual number of running gen-sets and
self Nomin power. This option is only active in parallel with mains, in island parallel
operation the mode is always internally set to LDSHARING.
LDSHARING The gen-set load is shared with other gen-sets according to the actual load.
#SysPFCtrl PtM [ BASEPF / VSHARING ]
BASEPF The gen-set power factor is controlled to a preadjusted level #SysPwrFactor. This
option is only active in parallel with mains, in island parallel operation the mode is
always internally set to VSHARING.
