VoltRegOut behavior in multi-gen-set applications
Operation mode Multiple Island Multiple Parallel to mains
Gen-set state Running,
GCB opened
Loaded island
GCB closed
MCB opened
Synchronizing Loaded in parallel
GCB closed
Active loop:
Volt gain, int;
Active loop:
VS gain, int;
Active loop:
Volt gain, int;
Active loop:
PF control
TauVoltActuat [ s ]
Time constant of the voltage regulator connected to the binary Up/Down outputs. This is to match the
reaction of the controller‘s regulator with the actual reaction time of the voltage regulator.
Step: 0,1 s
Range: 1,0 - 300,0 s
Force value: Yes
Hint:
Use this for older generators where motorised potentiometer is used for voltage adjust to the AVR.
Force value
Force value 1-16 [ X ]
„Source“ setpoints containing the alternative values for selected „target“ setpoints. The setpoint with index X
corresponds to the Force value Xth function. Procedure description see in GenConfig-x.y User guide.
Hint:
As the “source” for Force value channel can be used any compatible value in the controller (in general all
values and setpoints of types integer8,16,32). In that case the corresponding Force value X setpoint is
unused on that channel.
ExtValue1LoLim [ X ]
ExtValue2LoLim [ X ]
ExtValue3LoLim [ X ]
ExtValue4LoLim [ X ]
ExtValueX low limit. The value is not decreased under this limit, even if the request still exists (via binary
input ExtValueX down).
Step: 1 X
Range: -32000 – ExtValueXHiLim X
ExtValue1HiLim [ X ]
ExtValue2HiLim [ X ]
ExtValue3HiLim [ X ]
ExtValue4HiLim [ X ]
ExtValueX high limit. The value is not increased above this limit, even if the request still exists (via binary
input ExtValueX up).
Step: 1 X
Range: ExtValueXLoLim – 32000 X
