Page #39 background image
Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
39
StartStopBtn [ ENABLED / DISABLED ] (FV)
ENABLED: Standard settings for systems where engine start/stop and GCB is controlled from controller.
DISABLED: Disables the engine Start and Stop buttons and corresponding Binary start/stop signals.
ProtectionMode [ ACTIVE / NOT ACTIVE ] (FV)
ACTIVE: Standard setting – all protections are active.
NOT ACTIVE: Protections are indicated but does not change the controller states.
Recommended settings
StartStopBtn= DISABLED
ProtectionMode = NOT ACTIVE
Setting for systems where engine is started separately and GCB
is controlled externally (not from controller).
StartStopBtn= ENABLED
ProtectionMode = ACTIVE
Standard settings for system where engine start/stop and GCB is
controlled from controller.
Basic settings
Gen-set name
User-defined name, used for controller identification at remote connections. Gen-set name is max 15
characters long and has to be entered using PC software.
Hint:
The setpoint can be changed using PC SW only (e.g. InteliMonitor). Gen-set name isn’t affected by
GenConfig SW.
Nomin power [ kW ] (FV)
Nominal power of the generator.
Step: 1 kW
Range: 1 – 32000 kW
Force value: Yes
Nomin current [ A ] (FV)
This is the current limit for the generator. IDMT over current and short current protections are based on this
setpoint. See Generator protections: 2Inom del, Ishort setpoints. Nominal current can be different from
generator rated current value.
Step: 1 A
Range: 1 - 10000 A
Force value: Yes
!!! VERY IMPORTANT !!!
The maximum input current to the controller current terminals is 11 Amps. Higher value is
displayed as measured limit, e.g. 15 Amps from CT is measured and displayed as 11 Amps.
Take special care when selecting CT’s. All available 5 Amp CT’s do not have a range up to 11
Amps.
CT ratio prim [ A ]
Gen-set phases Current Transformers ratio – primary side.
Step: 1 A
Range: 1 – 10000 A
CT ratio sec [ /5A / /1A ]
Gen-set phases Current Transformers ratio – secondary side selection /5A or /1A. Available in IG-xxC and
IS-NT versions. In standard IG-EE/NT units only 5 A range available.
EarthFltCurCTp [ A ]
Earth Fault protection Current Transformer ratio – primary side.
Step: 1 A
