Functions
The IGS-NT-LSM+PMS dongle enables the Load sharing and Power management functions.
Modified setpoints
Below mentioned are GeCon specific setpoints only.
Group Setpoint Option Function
StartStopBtn
ENABLED
DISABLED
Standard panel Start/Stop buttons function.
Panel Start/Stop buttons are disabled.
Process control
ProtectionMode
ACTIVE
NOT ACTIVE
Standard MINT function.
2-nd level protections are blocked.
Sync timeout
1-1800s
NO TIMEOUT
Standard MINT function.
Unlimited synchronizing time.
GCB open level
1-100%
NO LEVEL
Standard MINT function.
No generator power open level detection.
Sync/Load ctrl
GCB open del
1-1800s
NO TIMEOUT
Standard MINT function.
Unlimited unloading procedure.
Hint:
All setpoints can be Forced by Binary input(s) to another value (or switched between ENABLED and
DISABLED).
Based on setpoint settings there are three possible operational modes HAND – MAN - AUT:
“HAND” MAN AUT
Basic setting ControllerMode
MAN MAN AUT
StartStopBtn
DISABLED ENABLED ENABLED
Process control
ProtectionMode
NOT ACTIVE ACTIVE ACTIVE
Sync timeout
NO TIMEOUT 1-1800s 1-1800s
GCB open level
NO LEVEL 1-100% 1-100%
Sync/Load ctrl
GCB open del
NO TIMEOUT 1-1800s 1-1800s
Hint:
It is possible to configure (Force value) “HAND” – MAN switching via Binary input.
OFF mode
Use OFF mode to block controller functions (even if is switched on). OFF mode is used for controller
firmware or configuration change.
Binary outputs (e.g. GCB CLOSE/OPEN) are not energized, all closed Binary outputs are opened when
controller is switched to OFF mode.
Gen-set cannot be started and operated from IG-NT-GeCon controller – no response for panell buttons and
Binary input commands.
Hint:
Switching to OFF mode is blocked on running engine to avoid accidental engine stop by mode change or by
firmware or configuration programming.
