Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
33
The output can be used for closing of MGCB (Master generator circuit breaker), because it activates if
sufficient number of gen-sets is available on the bus.
Hint:
Gen-set has to be included in Power Management System by closing of input Sys start/stop.
Gen-set has to be in AUT mode.
Setpoint Pwr management: Pwr management has to be ENABLED or EXTERNAL.
Syst res 1 OK … 4 OK
The corresponding output X is closed when Pwr management: #LoadResStrt X (or #%LdResStrt X in
relative mode) is achieved, independent to which #LoadResStrt X (or #%LdResStrt X) reserve is selected.
Analog inputs
RPM pick-up
Logical Analog input for RPM receiving from various types of Engine Control Units (and optionally via I-CB).
MLC:AnExSysBld
External requested System Baseload power value (Multi Load Control)
• Configure MLC:AnExSysBld to selected analog input
• Configure Analog input range
• Adjust
ProcessControl: SysBaseLdMode = EXTERNAL
LCD brightness
Analog input for external LCD brightness setting (e.g. via potentiometer). Keyboard LCD brightness setting
and binary input Alt brightness do not work when input is configured. Expected value is in the range 0 to
100%.
Hint:
Input available in IG-NT/EE and modifications only and valid only for the built-in display. For attached IG-
Display module, this input has no meaning. Input is not present in IS-NT.
Analog outputs
No analog output is available on IG-NT controller. Use extension unit IGS-PTM (one analog output) or I-
AOUT8 (eight analog outputs).
Analog values
EnginePriority Actual engine priority -
Act Reserve Actual load reserve kX = kW or kVA
Reserve Load reserve for start kX = kW or kVA
Reserve Stp Load reserve for stop kX = kW or kVA
ActRes rel Actual relative load reserve %
Res rel Load reserve for start %
ResStp rel Load reserve for stop %
MinR PWR Actual Min run power
TotRunPact Q Sum of reactive power kW
TotRunPact P Sum of active power kVAr
netPgnomPh
Sum of Nominal power on the
bus
kW
