82D-Link DIR-890L User Manual
Section 4 - Conguration - Router Mode
Static Routes
Name:
Destination Network:
Mask:
Gateway:
Metric:
Interface:
WAN
⌵
Create New Route
Apply
Status Name Destination Network Mask Gateway Metric Interface Edit Delete
DIR-890L HW:A1 FW:1.10
Features >> Static Routes >> IPv4
Static Routes
Once connected to the Internet, your router automatically builds routing tables that determine where trafc
should be sent. Static routes can override this process, allowing trafc to be directed to a specic client or
location.
Settings FeaturesHome Management
IPv6
Save
Remaining: 24
Add Rule
COPYRIGHT © 2016 D-Link
The Static Routes section allows you to dene custom routes to control how data trac is
moved around your network.
In the Features menu on the bar on the top of the page, click Static Routes.
To congure IPv6 rules, click IPv6 and refer to IPv6 on page 83. To return to the main
IPv4 static routes page, click IPv4.
If you wish to remove a rule, click on its trash can icon in the Delete column. If you wish
to edit a rule, click on its pencil icon in the Edit column. If you wish to create a new rule,
click the Add Rules button. Click Save when you are done. If you edit or create a rule, the
following options will appear:
Create New Rule
Name: Enter a name for the rule.
Destination
Network:
Enter the IP address of packets that will take this route.
Mask: Enter the netmask of the route.
Gateway: Enter your next hop gateway to be taken if this route is used.
Metric: The route metric is a value from 1 to 16 that indicates the cost of using
this route. A value 1 is the lowest cost and 15 is the highest cost.
Interface: Select the interface that the IP packet must use to transit out of the
router when this route is used.
Click Save when you are done.
