64D-Link DIR-890L User Manual
Section 3 - Conguration
Port Forwarding
Enter a Name for the new rule.
Enter the IP address of the computer on your local network that
you want to allow the incoming service to. Or, select the Computer
Name from the drop-down menu.
Enter a TCP Port (or a range of TCP ports) you want to open. Separate
ports with a comma (for example: 24,1009,3000-4000).
Enter a UDP Port (or a range of UDP ports) you want to open.
Separate ports with a comma (for example: 24,1009,3000-4000).
Use the drop-down menu to select a Schedule when the rule will
be enabled. The schedule may be set to Always Enable, or you can
create a schedules from the Schedules section (refer to page 73).
Click Apply when you are done.
Name:
Local IP:
TCP Port:
UDP Port:
Schedule:
If you wish to remove a rule, click on its trash can icon in the Delete column. If you
wish to edit a rule, click on its pencil icon in the Edit column. If you wish to create a
new rule, click Add Rule. Click Save when you are done.
When you click on Add Rule, the Create New Rule window will open. Enter the required
information into the elds described below:
Port forwarding allows you to specify a single port or a range of ports to open for specic devices on the network. It allows trac requests from a
specic application to be directed to a specic client.
From the Features menu, click Port Forwarding.
To Next Page
