65D-Link DIR-890L User Manual
Section 3 - Conguration
Virtual Server
Enter a Name for the new rule.
Enter the IP address of the device on your local network that you
want to allow the incoming service to or select the device from the
drop-down menu.
Select the protocol of the trac to allow or deny (TCP, UDP, Both, or
Other).
If you selected Other, enter the Protocol Number.
Enter the public port you want to open.
Enter the private port you want to open.
Use the drop-down menu to select a schedule when the rule will be
enabled. The schedule may be set to Always Enable, or create your
own schedule from the Schedules section (refer to page 73).
Click Apply when you are done.
The DIR-890L can store a maximum of 15 rules. If you wish to remove a rule, click on
its trash can icon in the Delete column. If you wish to edit a rule, click on its pencil
icon in the Edit column. If you wish to create a new rule, click the Add Rules button.
Click Save when you are done.
When you click on Add Rule, the Create New Rule window will open. Enter the required
information into the elds described below:
Name:
Local IP:
Protocol:
Protocol:
External Port:
Internal Port:
Schedule:
The Virtual Server allows you to specify a single public port for redirection to an internal LAN IP Address and Private LAN port.
From the Port Forwarding page click Virtual Server.
