73D-Link DIR-890L User Manual
Section 4 - Conguration
Schedule
Create schedules for use with enforcing rules. To create, edit, or delete
schedules, from the Time page click Schedule.
When you click on Add Rules, the following screen will appear:
First, enter the Name of your schedule.
Each row represents a day, and each box represents one hour, with the time at the
top of each column. To add a time period to the schedule, simply click on the start
hour and drag to the end hour. You can add multiple days to the schedule, but only
one period per day.
To remove a time period from the schedule, click on the cross icon at the end of the
row.
Click Apply when you are done.
If you wish to remove a rule, click on its trash can icon in the Delete column. If you
wish to edit a rule, click on its pencil icon in the Edit column. If you wish to create a
new rule, click the Add Rule button. Click Save when you are done.
