45D-Link ShareCenter DNS-345 User Manual
Section 4 - Conguration
Disk Management
Hard Drive Conguration
To setup the Hard Drive RAID conguration of your ShareCenter, click on the Management tab and then the Disk Management icon. Select the
Hard Drive Conguration menu item on the left of the window. This menu will allow you to set the RAID type and format your hard drives.
Hard Drive
Conguration:
Your ShareCenter hard drives can be
congured here and formatted in various RAID
congurations.
Current Raid Type: If the drives are already formatted the RAID
conguration will be displayed here.
Set RAID type and
Reformat:
Click on this button to launch a wizard that
allows you to select the RAID conguration
and format the drives.
Auto-Rebuild
Conguration:
If you have chosen RAID 1-5 as the conguration
option, then set the Auto-Rebuild function
here using the radio buttons.
Enable Auto-Rebuild: Enabling Auto-Rebuild will rebuild a failed
RAID 1-5 drive when a new drive has replaced
the degraded one.
Disable Auto-Rebuild: If you do not want to automatically rebuild
drives after a failure when using the RAID 1-5
functionality then you can check this option.
Note: You can still rebuild a drive using the RAID
1-5 functionality however you must initiate the
rebuild manually.
Manual Rebuild Now: If Auto-Rebuild is disabled then you can use
the Manual Rebuild option by clicking this
button.
