Daikin Maverick I Installation And Maintenance Manual

Daikin IM 972-1 11
Mechanical Installation
NOTICE: Derating of the heating input for high altitude in the
field is unlawful in Canada (refer to CAN/CGA 2.17). Units
installed in altitudes greater than 2,000 feet (610 meters) must
be shipped from the factory or from a factory authorized
conversion station with the heating input derated by 10% so as
to operate properly in altitudes from 2,000 - 4,500 feet (610
1,373 meters).
Condensate Drain
The condensate drain connection of the evaporator is threaded
1" nominal iron pipe.
IMPORTANT: Install a condensate trap to ensure proper
condensate drainage (see Figure 10).
Figure 10: Condensate Drain
Table 3: Meter Time In Minutes And Seconds For Normal Input Rating Of Furnaces Using Natural Or Lp Gas
Input
Btu/hr
Meter Size
Cu. Ft.
Heating Value Of Gas Btu Per Cu. Ft.
900 1000 1040 1100 2500
Mi
n. Sec. Min. Sec. Min. Sec. Min. Sec. Min. Sec.
40,000
One
Ten
1
13
21
30
1
15
30
0
1
15
34
36
1
16
39
30
3
37
45
30
60,000
One
Ten
0
9
54
0
1
10
0
0 10
3
24
1
11
6
0
2
25
30
0
80,000
One
Ten
0
6
41
45
0
7
45
30
0
7
47
48
0
8
50
15
1
18
53
45
100,000
One
Ten
0
5
33
24
0
6
36
0
0
6
38
15
0
6
40
36
1
15
30
0
Table 4: LP Gas Pipe Capacity (Cubic feet per hour)
Nominal Iron Pipe
Size, Inches
Length of Pipe, Feet
10 20 30 40 50 60 70 80 90 100
1/2 275 189 152 129 114 103 96 89 83 78
3/4 567 393 315 267 237 217 196 182 173 162
1 1,071 732 590 504 448 409 378 346 322 307
1-1/4 2,205 1,496 1,212 1039 913 834 771 724 677 630
1-1/2 3,307 2,299 1,858 1,559 1,417 1,275 1,181 1,086 1,023 976
2 6,221 4,331 3,465 2,992 2,646 2,394 2,205 2,047 1,921 1,811
