Control Inputs and Outputs
Control Outputs
Table 3: Control Outputs
Control Output Descriptions
(1) CC1 - Compressor output 1. The DDC Controller can
control the compressor contactors. The DDC Controller can
monitor the system and respond to system faults and comfort
alert inputs to shut down the compressors in the event of a
failure.
(2) CC2 - Compressor output 2. The DDC Controller can
control the compressor contactors. The DDC Controller can
monitor the system and respond to system faults and comfort
alert inputs to shut down the compressors in the event of a
failure.
(3) W1 - Heat output. The DDC Controller has two outputs to
control resistance electric heat.
(4) W2 - Heat Output. The DDC Controller has two outputs to
control resistance electric heat.
(5) G - Fan Output. The DDC Controller can control the
indoor fan by use of a fan relay.
(6) L - Thermostat signal. The “L” terminal will output a
flash code to an indoor 24 V thermostat equipped with an “L”
terminal.
Table 4: Thermostat Options
Table 5: Zone Sensor Module Wire Guide
1 CC1 - Compressor output 1 24VAC 1.5A @ 24VAC, pilot duty
2 CC2 - Compressor output 2 24VAC 1.5A @ 24VAC, pilot duty
3 W1 - Heat output 24VAC 1.5A @ 24VAC, pilot duty
4 W2 - Heat Output 24VAC 1.5A @ 24VAC, pilot duty
5 G - Fan Output 24VAC 1.5A @ 24VAC, pilot duty
6 L - thermostat signal 24VAC 25mA loading
Device Part Number Description
Stand alone 24V thermostat / touch screen 113129801 Up to 2-heat / 2-cool
Stand alone 24V thermostat 113129901 Up to 2-heat / 2-cool
Device
Part
Number
Wire
Gauge
Conductors Type Listings
Wall mounted sensor w/ tenant override 113117701 18 3 Solid 18 AWG 3/C CL2P Thermostat
Wall mounted sensor w/ space point adjustment 113117701 18 3 Solid 18 AWG 3/C CL2P Thermostat
