Electrical Data
Electrical Data
Compressor and Condenser Motor
Note: *Unit operating voltage range is 187 - 253
Note: *Unit operating voltage range is 414 - 506
Table 11: Compressor and Condenser Motor Data – 208/230 Volt
Data
Electrical Data (208/230 V)*
MPS
015B
MPS
020B
MPS
025B
Compressor Motor
No. 2
Phase 3
RPM 3450
HP, Compressor 1 7-1/2 10 11-1/2
Amps (RLA), Comp. 1 25 33.3 48.1
Amps (LRA), Comp. 1 164 239 245
HP, Compressor 2 7-1/2 7-1/2 11-1/2
Amps (RLA), Comp. 2 25 33.3 48.1
Amps (LRA), Comp. 2 164 239 245
Condenser Motor
No. 4 6
Phase 1
HP 1/3
Amps (FLA, each) 1.2
Amps (LRA, each) 4.7
Table 12: Compressor and Condenser Motor Data – 460 Volt
Data
Electrical Data (460 V)*
MPS
015B
MPS
020B
MPS
025B
Compressor Motor
No.
2
Phase 3
RPM 3450
HP, Compressor 1 7-1/2 10 11-1/2
Amps (RLA), Comp. 1 12.2 17.9 18.6
Amps (LRA), Comp. 1 100 125 125
HP, Compressor 2 7-1/2 7-1/2 11-1/2
Amps (RLA), Comp. 2 12.2 14.7 18.6
Amps (LRA), Comp. 2 100 95 125
Condenser Motor
No. 4 6
Phase 1
HP 1/3
Amps (FLA, each) 0.7
Amps (LRA, each) 2.4
