16 McQuay OM 1077
User Interface
Figure 8: Menu Structure
General information Screen
This is the home page of the system. At power up or after a
period of time of 5 minutes (display delay) without the
selection of any buttons, the system returns to this screen and
resumes scrolling through the items of this group.
The general information screen automatically scrolls through
the different menu items at 2-second intervals. When the user
presses any button, the changing of screens stops until the
display delay expires.
The software is programmed in the factory and cannot be
changed. The item “Alarms” is dependent upon the existence
of an alarm and it may display either “No Active Alarm” or
“Check Alarms!” Another screen outside this group shows the
details of existing alarms. The option for system configuration
is set with a configuration key from the factory.
Alarms
System
Configuration
Unit Status
Mode
Inputs
Outputs
Capacity %
Effect
Occupancy
Temperature
Space Temp
Eff Space Temp
Return Air Temp
Outside Air Temp
Eff Outside Air
Temp
Disch. Air Temp
Out Coil Temp 1
Out Coil Temp 2
Freeze sensor 1
Freeze sensor 2
Field Config 1
Field Config 2
Set points
Occ Cool/Heat
Unc Cool/Heat
Eff. Temp. SP
Cool Diff
Heat Diff
Min DAT spt
Max DAT spt
Sptnt Adj Enable
Setpoint Adjust
Hi balance point
Low balance point
Tmp Lockout Cool
Tmp Lockout Heat
Defrost Mode
Acc defrost time
Defrost SCT lim.
Economizer
Free Cooling
Econ. Status
Econ. Status
Enthalpy Setpt.
Eff. Mix. Air Temp
Mixed Air Setpt.
Ext. Mix. Air Temp
Econ. Vent. Lim
Econ. Exh. On/Off
Econ. DCV Limit
DCV Control
DCV Level Setpt.
Ext. DCV Level
Eff. DCV Level
Dff. Eco Position
Eff. Min. Position
Furnace Ctrl.
Device ID
IFC Fault
IFC Inputs
IFC Outputs
Time Delays
Demand Delay
Indr FanOn Dly
Indr Fan Off Dly
Keypad Tmr Lim
Compressors
ASCD
Comp. Min run
Tm.
Staging Time Dly
LPS Bypass Delay
HPS Bypass
Delay
Fan Proving SW
Clogged FilterSW
Smoke Alm
Switch
Ten. Over Time
INITIAL TEST SEQ
Pwd Required
ENTER PASSWORD
????
ACCESS DENIED/
GRANTED
Please see I&O
Section 6.10 for field
test sequence
History
of Alarms
Alarm # 1
Alarm # 2
Alarm # 3
Alarm # 4
Alarm # 5
Alarm 3 6
Alarm # 7
Alarm # 8
Alarm # 9
Alarm # 10
Active
Alarms
Active
Alarms
Defrost Comp. Off
Local Min. Pos.
Econ. Faults
Econ Firm Vrsn
All Sub-Menus highlighted gray
are user adjustable
Clear
Alarms?
General
Info
Software
Version
Occupied
Mode
Ind Fan
Occpcy
