Daikin IM 972-1 23
Physical Data
Physical Data
Unit Capacity and Physical Data
Table 10: MPS 015B – 025B
Model
MPS
015B 020B 025B
Cooling Performance
1
Gross cooling BTU [kW] 188,000 [55.08] 244,000 [71.49] 312,000 [91.42]
EER/SEER
2
11.1/NA 11.1/NA 10/NA
Nominal airflow/ARI airflow (cfm) [L/s] 6000/5900 [2831/2784] 8000/7725 [3775/3645] 10000/9475 [4719/4471]
Net cooling BTU [kw] 182,000 [53.33] 234,000 [68.56] 294,000 [86.14]
Net sensible BTU [kW] 135,700 [39.76] 171,600 [50.28] 214,100 [62.73]
Net latent BTU [kW] 46,300 [13.57] 62,400 [18.28] 79,900 [23.41]
Net system power kW 16.35 21.04 29.39
Compressor(s)
Type/number Scroll/2 Scroll/2 Scroll/2
Gas Heating Performance
3
AFUE % 808080
Steady stage efficiency % 81 81 81
No. stages 2 2 2
Gas connection size 1/2" - 3/4" 3/4" 3/4"
Heating input (BtuH) 250,000 / 350,000 300,000 / 400,000 300,000 / 400,000
Heating output (BtuH) 203,000 / 284,000 243,000 / 324,000 243,000 / 324,000
Temperature rise °F 15 - 60 15 - 55 10 - 45
Sound
4
Outdoor rating (dB) 91 91 92
Outdoor Coil
Fin type Louvered Louvered Louvered
Tube type Rifled Rifled Rifled
Tube size OD (in.) [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face area (sq. ft) [sq. m] 53.3 [4.95] 53.3 [4.95] 53.3 [4.95]
Rows (fpi) [fpcm] 1/22 [9] 2/22 [9] 2/22 [9]
Indoor Coil
Fin type Louvered Louvered Louvered
Tube type Rifled Rifled Rifled
Tube size OD (in.) [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face area (sq. ft) [sq. m] 26.67 [2.48] 26.67 [2.48] 26.67 [2.48]
Rows (fpi) [fpcm] 2/18 [7] 3/13 [5] 4/15 [6]
Refrigerant control TX valves TX valves TX valves
Drain connection (in.) [mm] 1" [25.4] 1" [25.4] 1" [25.4]
Condenser Fan
Type Propeller Propeller Propeller
No. used/diameter (in.) [mm] 4/24 [609.6] 6/24 [609.6] 6/24 [609.6]
Drive type/No. of speeds Direct/1 Direct/1 Direct/1
CFM [L/s] 16000 [7550] 19800 [9344] 19800 [9344]
Motor hp 4 at 1/3 HP 6 at 1/3 HP 6 at 1/3 HP
Motor rpm 1075 1075 1075
Indoor Fan
Type FC Centrifugal FC Centrifugal FC Centrifugal
No. used/diameter (in.) [mm] 2/18x9 [457x229] 2/18x9 [457x229] 2/18x9 [457x229]
No. motors 1 1 1
Motor hp (low static, high static) 3, 5 5, 7-1/2 7-1/2, 10
Motor rpm 1725 1725 1725
Filter
Fin type Disposable Disposable Disposable
Furnished Yes Yes Yes
No. size (in.) [mm]
(8) 2x25x20
[51x635x508]
(8) 2x25x20
[51x635x508]
(8) 2x25x20
[51x635x508]
Refrigerant
Charge oz. [g] 205/211 [5812/5982] 402/331 [11397/9384] 339/357 [9611/10121]
Weight
Net weight lbs. [kg] 2000 [907] 2341 [1062] 2433 [1104]
Shipping weight lbs. [kg] 2100 [953] 2441 [1107] 2533 [1149]
