Daikin Maverick I Installation And Maintenance Manual

Daikin IM 972-1 25
Electrical Data
Note: *Unit operating voltage range is 518 - 632
MCA and MCOP
Table 13: Compressor and Condenser Motor Data – 575 Volt
Data
Electrical Data (575 V)*
MPS
015B
MPS
020B
MPS
025B
Compressor Motor
No. 2
Phase 3
RPM 3450
HP, Compressor 1 7-1/2 10 11-1/2
Amps (RLA), Comp. 1 9.0 12.8 14.7
Amps (LRA), Comp. 1 78 80 100
HP, Compressor 2 7-1/2 7-1/2 11-1/2
Amps (RLA), Comp. 2 9.0 12.2 14.7
Amps (LRA), Comp. 2 78 80 100
Condenser Motor
No. 4 6
Phase 1
HP 1/3
Amps (FLA, each) 0.5
Amps (LRA, each) 1.5
Table 14: Unit MCA and MCOP Data
MPS Model
Voltage
208/230 460 575
Low Static
Fan Drive
High Static
Fan Drive
Low Static
Fan Drive
High Static
Fan Drive
Low Static
Fan Drive
High Static
Fan Drive
015
MCA 78.0 81.0 38.0 40.0 28.0 30.0
MCOP 100.0 100.0 45.0 50.0 35.0 35.0
020
MCA 101.0 109.0 52.0 56.0 40.0 42.0
MCOP 125.0 125.0 60.0 70.0 50.0 50.0
025
MCA 147.0 149.0 60.0 63.0 47.0 50.0
MCOP 175.0 175.0 70.0 80.0 60.0 60.0
