Daikin RXS30LVJU User Manual

SiUS091133 Troubleshooting
Service Diagnosis 134
4.23 Thermistor or Related Abnormality (Outdoor Unit)
Remote
Controller
Display
H9, J3, J6, P4
Method of
Malfunction
Detection
This fault is identified based on the thermistor input voltage to the microcomputer.
A thermistor fault is identified based on the temperature sensed by each thermistor.
Malfunction
Decision
Conditions
 The thermistor input voltage is above 4.96 V or below 0.04 V with the power on.
 J3 error is judged if the discharge pipe temperature is lower than the heat exchanger
temperature.
Supposed
Causes
 Disconnection of the connector for the thermistor
 Defective thermistor corresponding to the error code
 Defective heat exchanger thermistor in the case of J3 error (outdoor heat exchanger thermistor
in cooling operation, or indoor heat exchanger thermistor in heating operation)
 Defective outdoor unit PCB
Troubleshooting In case of “P4”
Replace the outdoor unit PCB.
P4 : Radiation fin thermistor
Caution
Be sure to turn off the power switch before connecting or disconnecting
connectors, or parts may be damaged.
