Indoor Unit: FTXS15/18/24LVJU SiUS091133
189 Removal Procedure
2.2 Removal of Front Grille
Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies
before disassembling work.
Step
Procedure Points
1. Remove the service
cover.
1
Remove the screw and
remove the service
cover.
You can remove the front grille
without detaching the service
cover.
2. Remove the front grille.
1
Remove the 3 screws
of the front grille.
Refer to the removal procedure
in a reverse way when
reassembling.
To Next Page
