Danfoss ECL Comfort 110 User Manual

VI.KT.G6.02 © Danfoss | 2016.05 | 11
Maintenance
Slope 2175
Setting range Factory setting
0.1 ... 4.0 1.2
Adjust the ‘Slope’ of the heat curve, if required.
The heat curve slope depends on the heating system and area specic design
parameters.
Example I
Design parameter:
Designed outdoor temperature (T
out
) -12 °C
Designed ow temperature (T
ow
) 80 °C
Designed room temperature (T
room
) 20 °C
For designed ow temperature higher than 40 °C, the heat curve slope (S) can be
calculated as:
S =
T
ow
- 25
2.5 x T
room
- T
out
- 30
S =
80 - 25
2.5 x 20 - (- 12) - 30
S ≈ 1.7
Example II
Design parameter:
Designed outdoor temperature (T
out
) -20 °C
Designed ow temperature (T
ow
) 35 °C
Designed room temperature (T
room
) 21 °C
For designed ow temperatures lower than 40 °C, the heat curve slope (S) can be
calculated as:
S =
T
ow
- 20
1.3 (2.5 x T
room
- T
out
- 30)
S =
35 - 20
1.3 (2.5 x 21 - (- 20) - 30)
S ≈ 0.3
For quick setting, the graph can be used. The graph is intended for a T
room
of 20 °C. If the
design data from example I is used, the slope will be approx. 1.7.
