Danfoss H1 Technical Information

Electric Displacement Control (EDC), option A2 (12 V)/A3 (24 V)
128.4 ±2
[5.055 ±0.079]
64.2 ±1
[2.528 ±0.039]
209 MAX
[8.228]
77.2 ±1
[3.039 ±0.039]
Connector :
Deutsch DT04-2P
To be paint free
Case gauge port "M14"
Port ISO 11926-1 -7/16-20
Ø21 max clearance dia for fitting
Shaft
Mounting flange
P003 330E
2x 139.3 ± 1
[5.484 ± 0.039]
Connector :
Deutsch DT04-2P
To be paint free
Shaft
178.86 ± 1
[7.042 ± 0.039]
2x 152.86 ± 1
[6.018 ± 0.039]
Please contact Danfoss Power Solutions representative for specific installation drawings.
Electric Displacement Control (EDC), with MOR, option A4 (12 V)/A5 (24 V)
2x 152.86 ± 1
[6.018 ± 0.039]
2x139.3 ± 1
[5.484 ± 0.039]
Connector :
Deutsch DT04-2P
To be paint free
Connector :
Deutsch DT04-2P
To be paint free
128.4 ± 2
[5.055 ± 0.079]
64.2 ± 1
[2.528 ± 0.039]
Case gauge port "M14"
Port ISO 11926-1 -7/16-20
∅21 max clearance dia for fitting
77.2 ± 1
[3.04 ± 0.039]
Shaft
Mounting flange
Shaft
178.86 ± 1
[7,042 ± 0.039]
209 MAX
[8.228]
P003 259E
Please contact Danfoss Power Solutions representative for specific installation drawings.
Technical Information
H1 Axial Piston Single Pumps, Size 069/078
Controls
54 11062169 • Rev 0700 • November 2015
