Danfoss VLT AHF 005 Instruction Manual

6.1.5 Main Menu Mode
Both the GLCP and NLCP provide access to the Main Menu
mode. Select the Main Menu mode by pressing [Main
Menu]. Figure 6.18 shows the resulting readout which
appears on the display of the GLCP.
Lines 2 to 5 on the display show a list of parameter groups
which can be selected by toggling [
▲
] and [
▼
].
130BP066.10
1107 RPM
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
3.84 A 1 (1)
Main Menu
Figure 6.18 Display Example
Each parameter has a name and a number, which remain
the same regardless of the programming mode. In the
Main Menu mode, the parameters are divided into groups.
The rst digit of the parameter number (from the left)
indicates the parameter group number.
All parameters can be changed in the Main Menu. The
conguration of the unit (parameter 1-00 Conguration
Mode) determines other parameters available for
programming. For example, selecting closed-loop enables
more parameters related to closed-loop operation. Option
cards added to the unit enable more parameters
associated with the option device.
6.1.6
Parameter Selection
In the Main Menu mode, the parameters are divided into
groups. Press the navigation keys to select a parameter
group.
The following parameter groups are accessible:
Group # Parameter group
0-** Operation/Display
1-** Load/Motor
2-** Brakes
3-** References/Ramps
4-** Limits/Warnings
5-** Digital In/Out
6-** Analog In/Out
8-** Comm. and Options
9-** Probus
10-** CAN Fieldbus
Group # Parameter group
11-** LonWorks
12-** Ethernet
13-** Smart Logic
14-** Special Functions
15-** FC Information
16-** Data Readouts
18-** Data Readouts 2
20-** FC Closed-loop
21-** Ext. Closed-loop
22-** Application Functions
23-** Time Actions
24-** Appl. Functions 2
25-** Cascade Controller
26-** Analog I/O Option MCB 109
30-** Special Features
31-** Bypass Option
35-** Sensor Input Option
Table 6.7 Parameter Groups
After selecting a parameter group, select a parameter with
the navigation keys.
The middle section on the GLCP display shows the
parameter number and name, as well as the selected
parameter value.
The middle section of the keypad display shows the
parameters. Press [OK] to select the parameters; the display
now shows the selected parameter's value.
130BP067.10
740RPM
0 -01 Language
[0] English
10.64A 1 [1]
0-0*
Basic Settings
Figure 6.19 Display Example
6.1.7 Changing Data
1. Press [Quick Menu] or [Main Menu].
2.
Press [
▲
] and [
▼
] to nd the parameter group to
edit.
3. Press [OK].
4.
Press [
▲
] and [
▼
] to nd the parameter to edit.
5. Press [OK].
How to Program
Instruction Manual
MG11F522 Danfoss A/S © 08/2014 All rights reserved. 107
6 6
