Danfoss VLT AHF 005 Instruction Manual

MCT 10 Set-up Software
MCT 10 Set-up Software has been designed as an easy-to-
use interactive tool for setting parameters in our adjustable
frequency drives.
The MCT 10 Set-up Software is useful for:
•
Planning a communication network
o-line. MCT
10 Set-up Software contains a complete
adjustable frequency drive database.
•
Commissioning adjustable frequency drives
online.
•
Saving settings for all adjustable frequency drives.
•
Replacing an adjustable frequency drive in a
network.
•
Simple and accurate documentation of adjustable
frequency drive settings after commissioning.
•
Expanding an existing network.
•
Supporting future-developed adjustable
frequency drives.
MCT 10 Set-up Software supports PROFIBUS DP-V1 via a
master class 2 connection. It enables online reading/
writing of parameters in an adjustable frequency drive via
the PROFIBUS network. This network eliminates the need
for an extra communication network.
Save adjustable frequency drive settings:
1. Connect a PC to the unit via USB com port.
(NOTE: Use a PC, which is isolated from line
power with the USB port. Failure to do so may
damage the equipment.
2. Open MCT 10 Set-up Software.
3.
Select Read from drive.
4.
Select Save as.
All parameters are now stored on the PC.
Load adjustable frequency drive settings:
1. Connect a PC to the adjustable frequency drive
via USB com port.
2. Open MCT 10 Set-up Software.
3.
Select Open – stored
les are shown.
4. Open the appropriate le.
5.
Select Write to drive.
All parameter settings are now transferred to the
adjustable frequency drive.
A separate manual for MCT 10 Set-up Software is available
at www.Danfoss.com/BusinessAreas/DrivesSolutions/Software-
download/DDPC+Software+Program.htm.
The MCT 10 Set-up Software modules
The following modules are included in the software
package.
MCT Set-up 10 Software
Setting parameters.
Copy to and from adjustable frequency drives.
Documentation and print of parameter settings,
including diagrams.
Ext. user interface
Preventive Maintenance Schedule.
Clock settings.
Timed Action Programming.
Smart Logic Controller Set-up.
Table 5.1 The MCT 10 Set-up Software Modules
Ordering number
Order the CD containing MCT 10 Set-up Software using
code number 130B1000.
The software can be downloaded from the Danfoss
internet site at www.Danfoss.com/BusinessAreas/DrivesSo-
lutions/Softwaredownload/DDPC+Software+Program.htm
5.3.3
Tips and Tricks
•
For most HVAC applications, the Quick Menu,
Quick Set-up and Function Set-up provide the
simplest and quickest access to the most required
parameters.
•
Whenever possible, performing an AMA ensures
the best shaft performance.
•
Adjust display contrast by pressing [Status] and
[
▲
] for darker display, or by pressing [Status] and
[
▼
] for brighter display.
•
Under Quick Menu and Changes Made, all
parameters which have been changed from
factory settings are displayed.
•
Press and hold [Main Menu] key for 3 s to access
to any parameter.
•
For service purposes, copy all parameters to the
LCP. See parameter 0-50 LCP Copy for further
information.
How to Operate the Adjustab...
Instruction Manual
MG11F522 Danfoss A/S © 08/2014 All rights reserved. 71
5 5
