International default value
North American default value
Parameter 1-23 Motor Frequency
Parameter 1-25 Motor Nominal Speed
Parameter 1-53 Model Shift Frequency
Parameter 1-56 U/f Characteristic
Parameter 6-15 Terminal 53 High Ref./Feedb. Value
Parameter 14-37 Fieldweakening Speed
11.4 Required Parameter Settings for Drive Options
On performing a factory reset on the drive, all drive parameters revert to their factory default value. Several drive options have pa-
rameter settings that must be configured differently from the factory default values in order for the options to perform properly.
Table 140: Parameter Settings for the Passive Filter Option (Typecode Character 7 = P/H/L/U)
Parameter 5-02 Terminal 29 Mode
Parameter 5-10 Terminal 18 Digital Input
Parameter 5-31 Terminal 29 Digital Output
[188] AHF Capacitor Connect
Parameter 14-51 DC-link Compensation
Table 141: Parameter Settings for the dU/dt Filter Option (Typecode Character 18 = D/1)
Parameter 5-10 Terminal 18 Digital Input
Parameter 14-52 Fan Control
1
This fan setting applies only to D9h and D10h models.
Table 142: Parameter Settings for the Sine-wave Filter Option (Typecode Character 18 = S/2)
Parameter 5-10 Terminal 18 Digital Input
Parameter 14-55 Output Filter
[2] Sine-Wave Filter Fixed
Table 143: Parameter Settings for the Indicator Light + Reset Button Option (Typecode Character 28–29 = D1/DA/DB/DC/DD/DE)
Parameter 5-40 Function Relay [1]
Parameter 5-40 Function Relay [2]
Parameter 5-14 Terminal 32 Digital Input
AQ262139143212en-000301 / 130R0879 | 193Danfoss A/S © 2021.10
Appendix
VLT® AutomationDrive FC 302
Operating Guide
