92 Printer Manager
MS2SSA1—Set the start sentinel adjustment for track 1. The start sentinel is encoded on the
magnetic stripe immediately before the first data character and indicates the beginning of
data. Enter a value from -4 to 4.
MS2StripeEncoderMultiplier—Enter a multiplier value to compensate for encoder variation.
MS2WriteTrack1—Allow magnetic stripe write actions to write to track 1.
MagStripeMS2CustomTrack1
Custom magnetic stripe settings are available for WebAdmin and WebService access levels to set
up custom secondary magnetic stripe options.
Change settings as needed, and then click Set Current to apply changes.
MS2CustomCharHigh1—Specify the numeric value of the highest ASCII character supported
for input data on the track.
MS2CustomCharLength1—Set the number of bits to represent one character of data on the
track, also called bits per character.
Description Default Value
Current Value
(unit) Allowed Range
1) MS2CustomCharHigh1 95 95 [0 – 255]
2) MS2CustomCharLength1 6 6 [1 – 8]
3) MS2CustomCharLow1 32 32 [0 – 255]
4) MS2CustomCharMask1 32 32 [0 – 255]
5) MS2CustomCharMax1 76 76 [0 – 255]
6) MS2CustomDensity1 210 210 [0 – 255]
7) MS2CustomEndSentinel1 63 63 [0 – 255]
8) MS2CustomLrc1 EVEN EVEN
9) MS2CustomParity1 ODD ODD
10) MS2CustomSdsNulls1 0 0 [0 – 255]
11) MS2CustomSdsRecords1 1 1 [0 – 255]
12) MS2CustomSdsSs1 1 1 [0 – 255]
13) MS2CustomStartSentinel1 37 37 [0 – 255]
