98 Printer Manager
Test Card
The Test Card menu shows the items available to WebAdmin access-level users. Print test cards
to troubleshoot card production issues. Select the options to test from the following.
Enter the value(s) for the type of test card to print, and then click Run to send the test card to
print.
Input Hopper Number—Select the input hopper from which the test card should be picked.
Test Card Print Options
Description Card Front (page 1) Card Back (page 2)
Input Hopper Number 1
Emboss [ ] TestCard1
Magnetic Stripe [ ]
Magnetic Stripe JIS [ ]
Color [ ] [ ]
Monochrome [ ] [ ]
Topcoat [ ] [ ]
Second Topcoat [ ] [ ]
Test Pattern to use for Color
and/or Monochrome
[TestPattern1] [TestPattern1]
Test Card Other Options
Description Current Value (unit) Allowed Range
Copies 1 [1 – 10]
Park Smart Card [ ]
Smart Card Park Time 10 seconds [0 – 300]
Do not eject card [ ]
