CE870 Instant Issuance System Installation and Administrator’s Guide 21
4. Reinstall the ribbon cartridge.
5. Close the printer swingarm. Press down on the
ridges on the front of the swingarm to make sure
that it latches completely on both sides.
6. Close the supplies access door. Leave the printer
unlocked to load cards into the multi-hopper.
Load the Print Ribbon (Optional)
The printer component uses print ribbon for optional color printing. If your printer is equipped
with the optional printhead, load the ribbon when you install the printer and when the ribbon
runs out.
1. Load the ribbon.
a. Load a full roll of print ribbon (the blue spool)
onto the spindle closest to the cartridge handle
until it clicks into place.
b. Place the silver take-up spool on the spindle
with the black gear until it clicks into place.
c. Wind the take-up spool counterclockwise one
full turn.
2. Replace the print ribbon cartridge.
3. Close the printer swingarm. Press down on the ridges on the front of the swingarm to make
sure that it latches completely on both sides.
4. Close the printer supplies access door on the multi-hopper.
5. Lock the printer.
