POWERSCAN
®
D8330/M8300/M8300-DK
6.2 16-KEY DK MESSAGE FORMATTING
The general Data Format shown remains valid for the Powerscan M8300 DK with
display and 16-key keypad. In addition, it also offers an extended message
formatting.
The table below describes conventions and definitions used in the examples on the
following page. In both the table and in the examples, formatting items valid only for
the 16-key model are shown in italics. The prefix C means programmed from the
standard Data Format parameters (beginning on page 69) and the prefix S means it
is programmed from the 16-key Display and Keypad Parameters (Data Format
section beginning on page 139).
The optional Header programmed from Display and Keypad
Parameters. It is additional to Header programmed from
general Data Format.
It can be:
o [ Scanner Data Header]
or
o [ Keypad Data Header]
depending on whether data is read from a barcode or
typed on the keypad.
The optional Terminator programmed from Display and
Keypad Parameters. It is additional to Terminator
programmed from general Data Format.
It can be:
o [Scanner Data Terminator]
or
o [ Keypad Data Terminator]
depending on whether data is read from a barcode or
typed on the keypad.
The optional Code ID formatting. It can be programmed:
• from General Data Format, represented in the following
as
[C ID]
• from specific Data Format Display and Keypad
Parameters, represented in the following as
[S ID]
