Datalogic PowerScan D8330 User Manual

TECHNICAL FEATURES
203
7 TECHNICAL FEATURES
7.1 POWERSCAN
®
D8330
Electrical Features
PowerScan® D8330 PowerScan® D8330 AR
Power Supply
4 to 30 VDC
Max. Consumption
@ 4V
@ 5V
@ 30 V
Sleep Mode
420 mA
310 mA
62 mA
4 mA
500 mA
370 mA
70 mA
4 mA
Reading Indicators
Good Read LED (green)
Good Read Spot (green), Beeper
Host Interfaces
RS-232
300 to 38400 baud
WEDGE
IBM AT or PS/2, XT, PC Notebook, IBM SURE1, IBM 3153, 31xx, 32xx,
34xx, 37xx terminals, Wyse terminals, Digital VT terminals, Apple ADB
Bus supported
PEN Emulation
Selectable minimum pulse from 200
µ
S to 1.2 mS
USB
USB-KBD, USB-KBD-ALT-MODE, USB-KBD APPLE, USB-COM, USB-
IBM-Table Top, USB-IBM-Hand Held
Laser Features
D8330 D8330 AR
Light Source
VLD between 630~680 nm
Scan Rate
35 ± 5 scans/sec
Power (max) in mW
0.9 mW
1.3 mW
Scan Angle
42°
13.5° ± 0.7
PCS minimum
(Datalogic Test Chart)
15% 25%
Maximum Resolution
0.076 mm (3 mils)
0.19 mm (7.5 mils)
Reading Field Width
see reading diagrams (par. 7.7)
Laser Safety Class
Class 2 EN 60825-1/CDRH
Environmental Features
Working Temperature -30° to +50 °C / -22° to +122 °F
Storage Temperature
-30° to +70 °C / -22° to +158 °F
Humidity
90% non condensing
Drop resistance (on concrete)
IEC 68-2-32 Test ED 2 m
Protection class
IP65
Mechanical Features
Weight (without cable)
about 295 g (10.4 oz)
Dimensions 205 x 114 x 69 mm (8.07 x 4.49 x 2.72 in)
Cable length 2 m (6 ft 6 in)
Material Polycarbonate molded with rubber
