88 H-Class
5.3 Reset Methods
There are three reset levels for the printer.
5.3.1 Soft Reset
Soft Reset clears temporary host settings. To perform a Soft Reset:
• Press and hold the CANCEL Key (see Section 4.1) for approximately four seconds.
5.3.2 Level One Reset
Level One returns the factory default settings, or if saved a Factory Setting File. To perform
a Level One Reset:
• Select SET FACTORY DEFAULTS in the menu; see Section 4.2.4.
5.3.3 Level Two Reset
Level Two returns the factory default settings and clears all parameters. To perform a Level
Two Reset:
• While turning ON the printer, press and hold the three Soft Keys (see Section 4.1)
until the SYSTEM RESET message flashes.
;
Calibration will be required; see Section 5.2.
5.4 Printhead Assembly Adjustments
Printhead Assembly Adjustments permit the mechanical compensation sometimes needed to
maintain print quality across the wide range of media types and sizes. The applicability and
adjustment methods for the printhead are described below.
5.4.1 Leveling Cam Adjustment
When using media that is less than full width of the printhead, adjust the Leveling Cam
(shown below) to evenly distribute the applied pressure.
;
If changing media sizes, readjust the Leveling Cam.
