4. Install the AC power cable to the EPA and secure with the wire clip.
5. Bend the AC power cable 180 degrees along the holder wall and through the cable cutout.
6. Secure the wire clip over the EPA cable.
Wall or ceiling installation
To install a single EPA power adapter holder on a wall or ceiling:
NOTE: This installation instruction procedure applies to the external power adapter.
You must order the mounting supplies for this installation separately. You need a drill and a pencil to complete this procedure.
1. Install the EPA in the power adapter holder using Steps 1 through 3 in the Power adapter holder assembly section.
2. Hold the EPA power adapter assembly to the wall or ceiling. Mark the screw-hole locations on the wall or ceiling with the
pencil.
3. Drill four holes in the wall or ceiling at the pencil marks.
4. Screw the power adapter holder assembly to the wall or ceiling using four screws.
Ceiling mount
44
External power adapter
