Dell 2155cn User Manual

104 Setting the IP Address
FILE LOCATION: C:\Users\fxstdpc-
admin\Desktop\0630_UG??\Mioga_AIO_UG_FM\Mioga_AIO_UG_FM\section08.fm
DELL CONFIDENTIAL – PRELIMINARY 9/13/10 - FOR PROOF ONLY
3 Click IP Configuration .
4 Follow the instructions displayed on the screen.
When Using the Operator Panel
For more information on using the operator panel, see " Operator Panel. "
1
Turn on the printer.
2 Press the (Menu) button.
3 Press button until System Setup is highlighted, and then press the
(Set) button.
4 Press button until Admin Menu is highlighted, and then press the
(Set)
button.
5 Press button until Network is highlighted, and then press the (Set)
button.
6 Press button until TCP/IP is highlighted, and then press the (Set)
button.
7 Press button until IPv4 is highlighted, and then press the (Set)
button.
8 Ensure that Get IP Address is highlighted, and then press the (Set)
button.
9 Press button until Panel is highlighted, and then press the (Set)
button.
Downloaded from ManualsPrinter.com Manuals

Dell 2155cn Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Internal memory	256 MB
Maximum internal memory	768 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	501 sheets
Multi-Purpose tray input capacity	1 sheets
Maximum duty cycle	40000 pages per month
Number of print cartridges	-
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4
Networking features	Gigabit Ethernet
Supported media weight(s)	60 - 216 g/m²
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Power consumption (printing)	- W
Display	LCD
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	400 x 406 x 413 mm
