114 Installing Printer Drivers on the Windows Computers
FILE LOCATION: C:\Users\fxstdpc-
admin\Desktop\0630_UG??\Mioga_AIO_UG_FM\Mioga_AIO_UG_FM\section10.fm
DELL CONFIDENTIAL – PRELIMINARY 9/13/10 - FOR PROOF ONLY
NOTE: The Select Printer window appears in this step when multiple
printer drivers are installed on your computer. In this case, click the name of
this printer listed in Printer Name, and then click OK.
The Tool Box opens.
2 Ensure that the Printer Settings Report tab is open.
3 Select TCP/IP Settings from the list at the left side of the page.
The
TCP/IP Settings page appears.
If the IP address shows
0.0.0.0 (the factory default), an IP address has not
been assigned. To assign one for your printer, see "Assigning an IP Address."
Disabling Firewall Before Installing Printer Software
NOTE: This step is necessary if you have Windows XP Service Pack 2 or 3
installed.
If your printer is connected directly to a network, and the Windows XP,
Windows Vista, Windows Server 2008, Windows Server 2008 R2, or Windows
7 firewall is enabled, you cannot view your networked printer(s) when you run
the Dell printer installation software. To prevent this situation, disable this
firewall before you install the Dell printer software. To disable or enable your
Windows XP, Windows Vista, Windows Server 2008, Windows Server 2008 R2,
or Windows 7 firewall, perform the following steps.
1
Click Start and click Help and Support .
NOTE: For Windows Server 2008 R2 and Windows 7, if you use Online
Help, switch to Offline Help on Windows Help and Support window.
2 In the Search box, type firewall , and then press the Enter key.
In the list, click
Turn Windows Firewall on or off , and then follow the
instructions on the screen.
Inserting the Drivers and Utility CD
1 Insert the Drivers and Utilities CD into your computer and click
setup_assist.exe to start Easy Setup Navigator .
NOTE: If the CD does not launch automatically, follow the procedure below.
For Windows XP, Windows Server 2008, and Windows Server 2008 R2
Click
start  Run , enter D:/setup_assist.exe (where D is the CD
drive letter) in the Run dialog box, and then click OK .
Downloaded from ManualsPrinter.com Manuals

Dell 2155cn Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Internal memory	256 MB
Maximum internal memory	768 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	501 sheets
Multi-Purpose tray input capacity	1 sheets
Maximum duty cycle	40000 pages per month
Number of print cartridges	-
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4
Networking features	Gigabit Ethernet
Supported media weight(s)	60 - 216 g/m²
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Power consumption (printing)	- W
Display	LCD
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	400 x 406 x 413 mm
