Replacing the bottom cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Tilt the computer towards the front until the base is facing up.
2 Align the tabs on the bottom cover with the slots on the chassis and snap the
bottom cover to lock it in place.
3 Replace the three screws (M3x5) that secure the bottom cover to the chassis.
4 Place the computer in an upright position.
Post-requisites
Replace the right-side cover.
112
